SAE adapter flange with measuring connection. Straight. Mounting: screw bore hole. To SAE J 518 C, ISO 6162. Black oiled surface. S355J2G3 (ST52.3). 12 sizes, each with its own part number.
Or call NZ 0800 668 874 · AU 1800 839 249 · US & CAN 437 245 6179
Tick the sizes you need, then request a price.
| Identification | Pressure series | PB 10.9 bar | Size | A | G mm | Ø B mm | C mm | D mm | E mm | F mm | L mm |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 3000 PSI | 350 | 1/2” | G 1/4”–19 | 24 | 12 | 38.1 | 55 | 17.5 | 38 | 9.0 | |
| 3000 PSI | 350 | 3/4” | G 1/4”–19 | 24 | 19 | 47.6 | 65 | 22.3 | 50 | 11.0 | |
| 3000 PSI | 315 | 1" | G 1/4”–19 | 24 | 24 | 52.4 | 70 | 26.2 | 50 | 11.0 | |
| 3000 PSI | 250 | 1.1/4” | G 1/4”–19 | 23 | 32 | 58.7 | 81 | 30.2 | 70 | 12.5 | |
| 3000 PSI | 200 | 1.1/2” | G 1/4”–19 | 24 | 38 | 69.9 | 95 | 35.7 | 78 | 13.5 | |
| 3000 PSI | 200 | 2" | G 1/4”–19 | 24 | 50 | 77.8 | 102 | 42.9 | 90 | 13.5 | |
| 6000 PSI | 400 | 1/2” | G 1/4”–19 | 24 | 12 | 40.5 | 55 | 18.2 | 38 | 9.0 | |
| 6000 PSI | 400 | 3/4” | G 1/4”–19 | 24 | 19 | 50.8 | 70 | 23.8 | 50 | 11.0 | |
| 6000 PSI | 400 | 1" | G 1/4”–19 | 23 | 24 | 57.2 | 81 | 27.8 | 70 | 13.0 | |
| 6000 PSI | 400 | 1.1/4” | G 1/4”–19 | 24 | 32 | 66.7 | 95 | 31.8 | 78 | 15.0 | |
| 6000 PSI | 400 | 1.1/2” | G 1/4”–19 | 24 | 38 | 79.4 | 112 | 36.5 | 94 | 17.0 | |
| 6000 PSI | 400 | 2" | G 1/4”–19 | 24 | 51 | 96.8 | 134 | 44.5 | 114 | 21.0 |
Note: The stated maximum working pressure relates to the flange. The actual working pressure is determined by the pipe (wall thickness) and the quality of the pipe.
