Screw-in socket, L shaped. Adjustable direction screw-in socket. BSP external thread, cylindrical. Thread socket with O-ring + spacer diaphragm ring. MotusCoat™ surface: up to 1,500 hours resistance to red rust in controlled testing, depending on specification and application. Steel. 19 sizes, each with its own part number.
Or call NZ 0800 668 874 · AU 1800 839 249 · US & CAN 437 245 6179
Tick the sizes you need, then request a price.
| Identification | G1 | G2 + G3 | SW mm | S1 | OR |
|---|---|---|---|---|---|
| G 1/8”-28 | G 1/8”-28 | 11 | 16 | 7.65 x 1.78 | |
| G 1/4”-19 | G 1/8”-28 | 14 | 20 | 10.78 x 2.62 | |
| G 1/4”-19 | G 1/4”-19 | 14 | 20 | 10.78 x 2.62 | |
| G 1/4”-19 | G 3/8”-19 | 19 | 20 | 10.78 x 2.62 | |
| G 3/8”-19 | G 1/4”-19 | 19 | 24 | 13.94 x 2.62 | |
| G 3/8”-19 | G 3/8”-19 | 19 | 24 | 13.94 x 2.62 | |
| G 3/8”-19 | G 1/2”-14 | 22 | 24 | 13.94 x 2.62 | |
| G 1/2”-14 | G 3/8”-19 | 22 | 28 | 17.86 x 2.62 | |
| G 1/2”-14 | G 1/2”-14 | 22 | 28 | 17.86 x 2.62 | |
| G 1/2”-14 | G 5/8”-14 | 22 | 28 | 17.86 x 2.62 | |
| G 1/2”-14 | G 3/4”-14 | 27 | 28 | 17.86 x 2.62 | |
| G 3/4”-14 | G 1/2”-14 | 27 | 35 | 23.47 x 2.62 | |
| G 3/4”-14 | G 3/4”-14 | 27 | 35 | 23.47 x 2.62 | |
| G 3/4”-14 | G 1”-11 | 33 | 35 | 23.47 x 2.62 | |
| G 1”-11 | G 3/4”-14 | 33 | 43 | 29.74 x 3.53 | |
| G 1”-11 | G 1”-11 | 33 | 45 | 29.74 x 3.53 | |
| G 1.1/4”-11 | G 1”-11 | 41 | 52 | 37.69 x 3.53 | |
| G 1.1/4”-11 | G 1.1/4”-11 | 41 | 52 | 37.69 x 3.53 | |
| G 1.1/2”-11 | G 1.1/2”-11 | 48 | 58 | 44.04 x 3.53 |
SW, S1, S2 = Width across flats
No size matches that. Clear the filter to see them all.
In controlled testing, MotusCoat™ achieves up to 1,500 hours resistance to red rust, depending on specification and application.
