Connectors. Angle 90°. BSP nut thread to uN / UNF external threads. 60° outer cone one end, 74° outer cone the other. MotusCoat™ surface: up to 1,500 hours resistance to red rust in controlled testing, depending on specification and application. Steel. 16 sizes, each with its own part number.
Or call NZ 0800 668 874 · AU 1800 839 249 · US & CAN 437 245 6179
Tick the sizes you need, then request a price.
| Identification | G1 | G2 | S1 | S2 |
|---|---|---|---|---|
| G 1/8”–28 | 7/16”-20 UNF | 14 | 13 | |
| G 1/4”–19 | 7/16”-20 UNF | 19 | 19 | |
| G 1/4”–19 | 1/2”-20 UNF | 19 | 19 | |
| G 1/4”–19 | 9/16”-18 UNF | 19 | 16 | |
| G 3/8”–19 | 9/16”-18 UNF | 22 | 19 | |
| G 3/8”–19 | 7/16”-20 UNF | 22 | 19 | |
| G 3/8”–19 | 3/4”-16 UNF | 22 | 19 | |
| G 3/8”–19 | 7/8”-14 UNF | 22 | 24 | |
| G 1/2”–14 | 3/4”-16 UNF | 27 | 22 | |
| G 1/2”–14 | 7/16”-20 UNF | 27 | 22 | |
| G 1/2”–14 | 9/16”-18 UNF | 27 | 22 | |
| G 1/2”–14 | 7/8”-14 UNF | 27 | 24 | |
| G 3/4”–14 | 1.1/16”-12 UN | 32 | 27 | |
| G 3/4”–14 | 7/8”-14 UNF | 32 | 27 | |
| G 1”–11 | 1.5/16”-12 UN | 41 | 46 | |
| G 1”–11 | 1.1/16”-12 UN | 41 | 36 |
SW, S1, S2 = Width across flats
No size matches that. Clear the filter to see them all.
In controlled testing, MotusCoat™ achieves up to 1,500 hours resistance to red rust, depending on specification and application.
