Bulkhead fitting socket, L shape. L shaped. MotusCoat™ surface: up to 1,500 hours resistance to red rust in controlled testing, depending on specification and application. Steel. 6 sizes, each with its own part number.
Or call NZ 0800 668 874 · AU 1800 839 249 · US & CAN 437 245 6179
Tick the sizes you need, then request a price.
| Identification | G1 - G3 | SW mm | S1 |
|---|---|---|---|
| 7/16”-20 UNF | 11 | 17 | |
| 1/2”-20 UNF | 14 | 19 | |
| 9/16”-18 UNF | 14 | 21 | |
| 3/4”-16 UNF | 19 | 25 | |
| 7/8”-14 UNF | 22 | 29 | |
| 1.1/16”-12 UN | 27 | 35 |
SW, S1, S2 = Width across flats
No size matches that. Clear the filter to see them all.
In controlled testing, MotusCoat™ achieves up to 1,500 hours resistance to red rust, depending on specification and application.
