Plug-in nipple, ORFS. UN / UNF nut threads. Flat sealing. To ISO 8434-3. MotusCoat™ surface: up to 1,500 hours resistance to red rust in controlled testing, depending on specification and application. Steel. 5 sizes, each with its own part number.
Or call NZ 0800 668 874 · AU 1800 839 249 · US & CAN 437 245 6179
Tick the sizes you need, then request a price.
| Identification | DN | Size | Inches | G1 | L1 | S1 |
|---|---|---|---|---|---|---|
| 6 | 4 | 1/4” | 9/16”–18 UNF | 36.0 | 18 | |
| 10 | 6 | 3/8” | 11/16”–16 UN | 40.0 | 22 | |
| 10 | 6 | 3/8” | 13/16”–16 UN | 43.0 | 24 | |
| 12 | 8 | 1/2” | 13/16”–16 UN | 47.0 | 24 | |
| 19 | 12 | 3/4” | 1.3/16”–12 UN | 67.0 | 35 |
Note: Undamaged nipples can be reused.
No size matches that. Clear the filter to see them all.
In controlled testing, MotusCoat™ achieves up to 1,500 hours resistance to red rust, depending on specification and application.
