Screw-in socket, L shaped. Adjustable direction screw-in socket. Metric cylindrical outer thread. Thread socket with O-ring + spacer diaphragm ring. MotusCoat™ surface: up to 1,500 hours resistance to red rust in controlled testing, depending on specification and application. Steel. 11 sizes, each with its own part number.
Or call NZ 0800 668 874 · AU 1800 839 249 · US & CAN 437 245 6179
Tick the sizes you need, then request a price.
| Identification | G1 | G2 + G3 | SW mm | S1 | OR |
|---|---|---|---|---|---|
| M 12 x 1.5 | G 1/8”-28 | 13 | 18 | 9.3 x 2.4 | |
| M 12 x 1.5 | G 1/4”-19 | 14 | 18 | 9.3 x 2.4 | |
| M 14 x 1.5 | G 1/4”-19 | 14 | 20 | 11.3 x 2.4 | |
| M 14 x 1.5 | G 3/8”-19 | 19 | 20 | 11.3 x 2.4 | |
| M 16 x 1.5 | G 1/4”-19 | 19 | 22 | 13.3 x 2.4 | |
| M 16 x 1.5 | G 3/8”-19 | 19 | 22 | 13.3 x 2.4 | |
| M 18 x 1.5 | G 3/8”-19 | 22 | 24 | 15.3 x 2.4 | |
| M 18 x 1.5 | G 1/2”-14 | 22 | 24 | 15.3 x 2.4 | |
| M 20 x 1.5 | G 1/2”-14 | 22 | 28 | 17.3 x 2.4 | |
| M 22 x 1.5 | G 1/2”-14 | 22 | 28 | 19.3 x 2.4 | |
| M 22 x 1.5 | G 3/4”-14 | 27 | 28 | 19.3 x 2.4 |
SW, S1, S2 = Width across flats
No size matches that. Clear the filter to see them all.
In controlled testing, MotusCoat™ achieves up to 1,500 hours resistance to red rust, depending on specification and application.
