Two-Way High Pressure Ball Valve (Steel)
Carbon Steel | Handle Operated | BSP Thread | Up to 500 Bar. Connects by handle. Interchanges with Hydac KHB series Hydac KHM series Pister BKH series. Working pressure up to 500 bar. -25 °C to +125 °C. Zinc plated surface. Steel. 5 sizes, each with its own part number.
Or call NZ 0800 668 874 · AU 1800 839 249 · US & CAN 437 245 6179
Tick the sizes you need, then request a price.
| Part No. | Body Size | DN | L1 mm | L2 mm | L3 mm | H mm | G mm | L4 mm | L5 mm Width | L6 mm | T | Max Working Pressure (Bar) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1/8” | 4 | 69 | 40 | 154.1 | 73 | 4.5 | 26 | 26 | 33 | 1/8 BSPF | 500 | |
| 1/4” | 6 | 69 | 40 | 145 | 71 | 4.5 | 26 | 26 | 33 | 1/4 BSPF | 500 | |
| 3/8” | 10 | 71 | 42 | 145 | 76.5 | 6.5 | 32 | 33 | 38 | 3/8 BSPF | 500 | |
| 1/2” | 13 | 82 | 48 | 161 | 81 | 6.5 | 37.5 | 36 | 40 | 1/2 BSPF | 500 | |
| 3/4” | 20 | 96 | 62 | 218 | 112 | 6.5 | 49 | 49 | 57 | 3/4 BSPF | 315 |
Series: LL = Very Light L = Light S = Heavy PN = Nominal pressure PB = Max. operating pressure Ø d2 = External pipe diameter Product Versions: Metric Male / NP Tapered Male (GE - NPT) VA - Screw-in fitting, Stainless steel | VN - Screw-in fitting, Steel
